Who should attend the Course
Any who wants to learn AUTOCAD for Railway Signaling
Participants with working experience
•Participants without working experience
•Engineering graduates (other than civil engineering)
•Diploma holders (other than civil engineering )
Science graduates.
Certificate and Assessment
Trainees will be required to complete an assignment which shall be reviewed by a trainer and upon satisfactory appraise by trainer, a certificate of completion shall be awarded to trainees
Example Curriculum
What is covered in training
Session 1
1.Introduction of AUTOCAD.
2.Importance of AUTO CAD In Signalling.
3.Basics of Terminology used in AUTOCAD.
4.Introduction of different types of toolbars & displays present, their Units and their settings.
Session 2
1.Settings needed before starting a drawing.
2. Scale arrangements, Grid arrangements.
3.Basic drawing tool moments used and there shortcuts.
4.Output Print Settings and image previews.
Session 3
1.All Major drawing tools for drawing with properties and shortcuts.
2.Layers , Types of layers ,their arrangements and Dimensions.
Session 4
1.Grouping.
2.Text Insertion
3.Enabling of properties
4.combinations of drawings using various shortcuts and their settings.
Session 5
1.Quick Recap.
2.Doubts clarifications.
Railway Academy Advantage
Get exclusive invites and offers to our upcoming programs with alumni discounts to learn and grow lifelong
Get one year access with all course upgrades available to you free of cost.
Job Opening Alerts and support to get the dream job in signaling
